2" Back Mount 1/4 Liquid Filled 200 Psi Compressed Air Compressor
Pressure Gauge
USD $25.95
Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
Liquid filled air pressure gauge. This gauge has a glycerine filling that helps dampen the effects of pulsation and vibration, while also perpetually lubricating the movement, and keeping contaminates such as dirt away from all moving parts, which will extend the life of the gauge.
This gauge reads at 0, 40, 80, 120, 160, and 200 PSI with tac marks every 5 PSI
BAR readings at 2,4,6,8,10,12, and 14
Specifications:
• Dial Size: 2"
• Center Bottom Mount
• Connection Size: 1/4" Male NPT
• Stainless Steel Case & Bezel
• Brass Connection and Internals with built in Snubber
• Phosphor Bronze Bourdon Tube
• Glycerine Filled
• Accuracy: 3-2-3% per ANSI grade B
• Dual Scale: PSI / BAR (x100=kPa)
• Ambient Temperature: 30°F to 160°F
.
